Savage Raven 霧鴉（Skull ＆ Co.）

Jumpgate Multifunctional Expansion Portable Dock for Nintendo Switch 2/NS1 (Original/V2/OLED)

Jumpgate Multifunctional Expansion Portable Dock for Nintendo Switch 2/NS1 (Original/V2/OLED)

TWD$1,199
TWD$1,229 TWD$1,199
2%折扣 Sold out
Tax included. Shipping calculated at checkout.
type
7-11 FamilyMart SF master visa JCB

All products pass the EU RoHS non-toxic environmental standards

View full details

product description


for Nintendo Switch

Jumpgate Multi-functional Dock

Switch 2 · Switch Original/Enhanced Power/OLED Model

Key Features

Modular Design — The micro Core Drive and dock casing are detachable.

One Dock for Multiple Uses — The detachable micro core is suitable for Switch NS2/NS1 and handhelds like Steam Deck, ROG Ally, and XBOX Ally.

High-Resolution Output — Supports up to 8K@30Hz, 4K@120Hz.

Unrivaled Portability — The micro core is small and lightweight, making it easy to carry.

Case Compatibility — No need to remove your protective case when connecting to the dock (except for NS2 StandGrip).

Supports DeX Mode — DeX-enabled smartphones can output video to a TV.

Wide Connectivity — The micro core can be used as a USB Hub, providing HDMI 2.1 and USB 3.0 slots (Pro version).

Version Comparison

LITE

Suitable for those who simply want to replace the original dock, with 1 x USB 2.0 slot for external accessories, for light use.

PRO

Suitable for hardcore gamers, with 3 x USB 3.0 slots for faster transfer speeds, supporting more external accessories or laptop expansion.

Compatible Cases from this Brand

  • NS2 — FissionGrip Detachable Soft Grip Case
  • NS2 — NEOGrip2 Grip Case
  • NS2 — GripCase2 Soft Grip Case
  • NS1 — NEOGrip Grip Case
  • NS1 — GripCase Clear Grip Case
💡 Can be paired with "USB Wired Network Mini Adapter" to expand wired network connectivity.
💡 The Core Drive micro core can be updated via the firmware update tool.

Technical Specifications

🎮 Micro Core Drive

  • Dimensions: 88 x 37 x 10mm｜Material: ABS+PC
  • 1x HDMI 2.1 (up to 8K@30Hz, 4K@120Hz)
  • 1x Type-C 3.1 (up to 100W full-speed power delivery)
  • 3x USB 3.0 (Pro version) — Max 10W, 5Gbps transfer speed
  • 1x USB 2.0 (Lite version) — Max 10W, 480Mbps transfer speed
  • DC/DC Efficiency: Up to 96%｜Operating Temperature: Below 46°C

🎮 Portable Jumpgate Dock

  • Dimensions: 107 x 100 x 25mm｜Material: ABS+PC
  • 1x Type-C 3.1 Male (full function)
  • 1x Type-C 3.1 Female (up to 100W)

⚡ 65W GaN Charger (Add-on Option)

  • Dimensions: 83.7 x 46 x 16mm｜Weight: 68g｜Material: Fire-resistant PC
  • Input: 100V-240V ~ 50/60Hz 0.6A max
  • Type-C: 5V=3A / 9V=3A / 12V=3A / 15V=3A / 20V=3.25A — 65W MAX
  • USB-A: 5V=3A / 9V=2A / 12V=1.5A — 18W MAX
  • USB-A + Type-C Simultaneously: 5V 2.4A + 45W

Contents

  • 1x Portable Jumpgate Dock Casing
  • 1x Micro Core Drive (installed in the dock)
  • 1x Product User Manual
🔴 Due to the multi-purpose nature of the core chip, CEC function is not supported for compatibility reasons.
⚠️ Without the micro Core Drive, the dock casing cannot output video and audio to a TV.
⚠️ The Type-C connector is compatible with protective cases with a thickness of no more than 1.5mm. As the micro core connector is short, it is not recommended to use the micro core alone to connect a Switch with a protective case.
⚠️ Due to the wide variety of laptop models on the market, compatibility issues may occur with some laptops, and applicability to all laptops cannot be guaranteed.
⚠️ Type-C version iPads, iPad Pros, iPhones, and MacBooks can output video.

This product does not support HDMI-CEC.

Compatible Products

Compatible with the following products

  • ■NS2 MAX Storage Bag
    Can be placed directly into the lower compartment.
  • ■NS2 FISSIONGRIP
    Can connect to output without removing the case.
  • ■NS2 NEOGRIP2
    Can connect to output without removing the case.
  • ■NS2 GRIPCASE2
    Can connect to output without removing the case.
  • ■USB Wired Network Mini Adapter
    Can be connected for USB expansion.
  • ■AUDIOSTICK Bluetooth Transmitter
    Can be connected for USB expansion.
  • ■AUDIODRIVE Bluetooth Transmitter
    Can be connected for USB expansion.

常見問題 Q&A

JUMPGATE
Q 與SWITCH原廠底座相比，JUMPGATE有哪些優勢？？

JUMPGATE底座比原廠底座小巧，模組化設計可拆卸的微型核心體積極小，更方便攜帶。此外，微型核心還可以用作筆記型電腦的USB Hub集線器，且支援高達4K@144Hz的影像輸出，並且支援DeX功能，可以讓手機轉換為DeX模式。

Q JUMPATE兩個版本有什麼不同？

LITE版：一個USB 2.0插槽

PRO版：三個USB 3.0插槽

Q SWITCH 2裝上保護殼後還能連接JUMPGATE底座嗎？

可以的，相容厚度不超過1.5MM的保護殼，不需拆卸保護殼即可連接輸出。

＊請注意，本品牌NS2 STANDGRIP因為較厚不支援。

Q JUMPGATE底座最高支援輸出解析度是多少？

SWITCH 2：最高支援4K@120Hz（120Hz需要遊戲支援）

SWITCH OLED：最高支援1080P

筆記型電腦：最高支援8K@30Hz

DeX智慧型手機：最高支援2K@120Hz

Q JUMPGATE支援喚醒和CEC功能嗎？

支援控制器喚醒功能，但不支援電視CEC功能。

Q 為什麼在電視/顯示螢幕上沒有影像？

首先，請確認你所使用的電源是符合輸出要求的（NS2原廠充電器或65W以上電源）。

如果輸出要求正確，可以嘗試以下方式排查：

  1. 將微型核心(CORE DRIVE)拆卸出來，直接連接Switch 2主機檢查輸功能是否正常。
  2. 將Switch 2主機放在JUMPGATE底座外殼上（微型核心拔出），將USB-C線材直接連接JUMPGATE底座外殼，檢查是否能充電。
  3. 檢查電視或顯示螢幕設定，某些品牌可能有某些設定模式影響導致無法輸出，例如：增強模式（開／關）

如果已經嘗試多種交叉測試方法後仍無法解決，請透過右下角“協助“視窗與我們客服聯絡處理。

Q JUMPGATE底座有乙太網路連接孔嗎？

為了纖薄和便攜性，JUMPGATE底座沒有配備乙太網路孔，但你可以透過USB-A外接乙太網路轉接頭來使用有線網路。

Q 可以使用JUMPGATE將影像畫面輸出到筆記型電腦嗎？

不可以的，底座沒有擷取功能，因此無法輸出至筆記型電腦。

Q JUMPGATE底座外殼上的USB-C接頭會搖晃，這會對Switch有影響嗎？

不會的，這不會對你的Switch造成影響。

我們設計的USB-C接頭位置具有5 °可調節角度功能，這有助於防止在插拔過程造成損壞，同時高低調整也可以相容保護殼使用。
